On-Demand Customization Molybdenum Bar Molybdenum Strip For Molybdenum Products
The Achemetal company's products contain tungsten, molybdenum, TZM, high temperature molybdenum and other metals, raw materials are selected from high-purity powder, rod billet impurity content is low, high sintering density, forging the finished product deformation.
The processing process focuses on the control of the forging process, supplemented by the hot isostatic pressing process when necessary, to ensure that the product is high density, fine grain, and easy to deep processing characteristics.
The high density and fine grain tungsten-molybdenum alloy forging products have become one of the characteristics of Achemetal's products.
Application:Tungsten and molybdenum forging products are widely used by post-processing in.
- Tungsten electrode, molybdenum electrode, molybdenum stirring bar, molybdenum flow port in quartz, glass smelting, glass fiber, aluminosilicate cotton and rare earth smelting industries
-
- Tungsten weight hammer, molybdenum weight hammer, tungsten wire rope, fasteners, etc. in the single crystal silicon industry
-
- Tungsten support column and molybdenum support column for vacuum furnace such as sapphire crystal furnace
-
- Tungsten rod heaters and tungsten wire mesh heaters for vacuum furnaces such as sapphire crystal furnaces
-
- Tungsten electrode and molybdenum electrode for welding
-
- Tungsten tube, molybdenum tube
-
- The high temperature resistant parts, such as the parts of ion source in ion implantation equipment
-
- Radiation shielding parts, etc.
Specification details
| Name | Size |
| Wire | Ф0.5~Ф3.0 |
| Rod ,bar | Ф2~Ф200 |
| Cake, block Single | weight within 100KG |
Molybdenum ASTM B387
| TABLE1 Chemical Requirements |
| Element | Composition,% |
| Material Number |
| 360 | 361 | 363 | 364 | 365 | 366 |
| C | 0.030max | 0.010max | 0.010-0.030 | 0.010-0.040 | 0.010max | 0.030max |
| O,MAXA | 0.0015 | 0.0070 | 0.0030 | 0.030 | 0.0015 | 0.0025 |
| N,MAXA | 0.002 | 0.002 | 0.002 | 0.002 | 0.002 | 0.002 |
| Fe,MAX | 0.010 | 0.010 | 0.010 | 0.010 | 0.010 | 0.010 |
| Ni,MAX | 0.002 | 0.005 | 0.002 | 0.005 | 0.002 | 0.002 |
| Si,MAX | 0.010 | 0.010 | 0.010 | 0.005 | 0.010 | 0.010 |
| Ti | ... | ... | 0.40-0.55 | 0.40-0.55 | ... | ... |
| W | ... | ... | ... | ... | ... | 27-33 |
| Zr | ... | ... | 0.06-0.12 | 0.06-0.12 | ... | ... |
| Mo | balance | balance | balance | balance | balance | balance |
A Pending approved methods of analysis,deviations these limits alone sahll not be cause for rejection.
| TABLE2 Permissible Variations in Check Analysis |
| | Material NO. | Check Analysis Limits,max or range,% | Permissible Variations in Check Analysis,% |
| C | 360, 363, 364, 366, 361, 365 | 0.010–0.040 0.010 | ±0.005 ±0.002 |
| OA | 361 360, 363, 365, 366 364 | 0.0070 0.0030 0.030 | +10 % relative +10 % relative +10 % relative |
| NA | 361, 364, 365 360, 363, 366 | 0.0020 0.0010 | +0.0005 +0.0005 |
| Fe | 360, 361, 363, 364, 365, 366 | 0.010 | +0.001 |
| Ni | 360, 361, 363, 364, 365, 366 | 0.005 | +0.0005 |
| Si | 360, 361, 363, 364, 365, 366 | 0.010 | +0.002 |
| Ti | 363, 364 | 0.40–0.55 | ± 0.05 |
| W | 366 | 27.0–33.0 | ±1.0 |
| Zr | 363,364 | 0.06–0.12 | ±0.02 |
ASee Table 1, Footnote A.
Process Flow
FAQ
Q1: Can I order a sample quantity ?
A1: Yes,if you offer the freight cost.
Q2: Can I add my logo on the boxes/cartons?
A2: Yes,OEM and ODM are available from us.
Q3: What are the benefits of being a distributor ?
A3: Special discount Marketing protection.
Q4: Can we mix items in one 20ft container?
A4: Yes.
Q5: Can I have a visit to your factory before the order?
A5: Sure,welcome your visit of factory.
Q6:What payment options do we offer?
A6:L/C ,T/T,Western union,MoneyGram
Supply Ability
5000 Kilogram/Kilograms per Month
Packaging & Delivery
Packaging Details
Standard Wooden Package with foam filling and steel belt tightening ；
With special needs, the box is covered with plastic film to waterproof.
Small products are sent by carton express.
Port
Shanghai Tianjin Qingdao etc.
Lead Time:
| Quantity(kilograms) | 1 - 500 | 501 - 1000 | >1000 |
| Est. Time(days) | 15 | 30 | To be negotiated |
Picture Example:
L
Product Tags:
|
|
Customization Molybdenum Strip Images
|
